AIRPAX/SENSATA toggle handle hydraulic magnetic circuit breaker with rechargeable automatic fuse

Name: AIRPAX/SENSATA toggle handle hydraulic magnetic circuit breaker with rechargeable automatic fuse
Brand: Osculati
SKU: E4377
Price: 25.6 EUR
Availability: InStock

Product code: E437700

Lever

Within 24 hours

€25.60 €26.90 -4.83%

Variant Choice

Selected variant code E437700

Estimated delivery to Italy: by Fri 18 Sep (for orders received by 1:00PM)

Update prices and delivery times for your country

Description

Designed on purpose for the marine environment. In case of heavy overload (i.e.: short circuits), the circuit breaker disconnects instantaneously; for overloads up to 50% it maintains the contact for few seconds so, in case it is due to a chance event, it has time to return within the limits without interrupting the power supply. In case of short circuit, the switch cannot be reactivated until the problem is solved.
- Toggle handle circuit breaker - Toggle actuator, IAG series, universal 12/220 V, front recess in the panel, 16-mm Ø.
- Flat flush toggle circuit breaker for horizontal or vertical mounting - Flat actuator with flush toggle, coloured light indicator for OFF position. IEGB series, universal 12/220 V, front recess in the panel 32x19-mm.

EAN13 8033137092046

MPN 14.736.05

PDF Catalog Download (526.45KB)

Choose the model

Code	Add to cart	Variant Choice	Flush toggle switch	Universal supply	Capacity A	Price
E437700	add to cart	protrudring lever 5A	Switch with protruding lever	DC/AC 12/220 V	5	~~€26.90~~ €25.60
E437701	add to cart	protrudring lever 10A	Switch with protruding lever	DC/AC 12/220 V	10	~~€26.90~~ €25.30
E437702	add to cart	protrudring lever 15A	Switch with protruding lever	DC/AC 12/220 V	15	~~€26.90~~ €25.30
E437703	add to cart	protrudring lever 20A	Switch with protruding lever	DC/AC 12/220 V	20	~~€26.90~~ €25.60
E437704	add to cart	protrudring lever 50A	Switch with protruding lever	DC/AC 12/220 V	50	~~€26.90~~ €25.60
E437710	add to cart	flush lever vertical 5 A	vertical mounting	DC/AC 12/220 V	5	~~€28.90~~ €28.10
E437711	add to cart	flush lever vertical 10 A	vertical mounting	DC/AC 12/220 V	10	~~€28.90~~ €28.10
E437712	add to cart	flush lever vertical 15 A	vertical mounting	DC/AC 12/220 V	15	~~€28.90~~ €28.10
E437713	add to cart	flush lever vertical 20 A	vertical mounting	DC/AC 12/220 V	20	~~€28.90~~ €28.10
E437714	add to cart	flush lever vertical 50 A	vertical mounting	DC/AC 12/220 V	50	~~€28.90~~ €28.10
E437720	add to cart	flush lever horizontal 5 A	horizontal mounting	DC/AC 12/220 V	5	~~€28.90~~ €28.10
E437721	add to cart	flush lever horizontal 10 A	horizontal mounting	DC/AC 12/220 V	10	~~€28.90~~ €28.10
E437722	add to cart	flush lever horizontal 15 A	horizontal mounting	DC/AC 12/220 V	15	~~€28.90~~ €28.10
E437723	add to cart	flush lever horizontal 20 A	horizontal mounting	DC/AC 12/220 V	20	~~€28.90~~ €28.10
E437724	add to cart	flush lever horizontal 50 A	horizontal mounting	DC/AC 12/220 V	50	~~€28.90~~ €28.10
