LEWMAR V3 GD/GO windlass, 1000W

Name: LEWMAR V3 GD/GO windlass, 1000W
Brand: Osculati
SKU: G0250
Price: 762.9 EUR
Availability: OutOfStock

Product code: G025091

Lewmar V3 windlass gypsy

Out-of-Stock

€762.90 €779.00 -2.07%

Variant Choice

Selected variant code G025091

Description

- Rope/chain gypsy.

- AISI316 stainless steel deck unit.

- FastFit: new patented motor mounting option for quicker installation.

- Fall Safe anchor lock.

- Modern design.

- ready to fit chain counter sensor.

- IP68 waterproof unit.

MPN 02.511.01

PDF Catalog Download (573.94KB)

Choose the model

Code	Add to cart		Variant Choice	Version	Motor - V	Motor - W	Weight	For boats	Current draw A	Gypsy - chain Ø mm	Gypsy - Line Ø mm	Pull kg - max	Pull kg - continuous	Recommended circuit breaker A	Single parts - Only gypsy	Single parts - Only solenoid	Line speed m / min - max	Line speed m / min - continuous	Single parts - Only deck unit	Single parts - Only motor/gearbox	Price
G025091	add to cart	-	Outdoor unit only for V2/V3 low	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	~~€779.00~~ €762.90
G025092	add to cart	-	Outdoor unit only for V2/V3 high	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	~~€1,034.00~~ €1,016.00
G025093-012	add to cart	-	12V motor/gearbox only	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	~~€1,159.00~~ €1,137.50
G025094-024	add to cart	-	24V motor/gearbox only	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	~~€1,159.00~~ €1,137.50
G025010	add to cart	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	~~€239.50~~ €234.70
G025008-012	add to cart	-	Low - 12V - Chain Ø8 mm	GO	12	1000	21	12 to 16 m	85	8	12-16	890	223	110	[02.519.08]	[02.590.01]	28	18	[02.511.01]	[02.516.12]	~~€2,214.00~~ €2,172.60
G025010-012	add to cart	-	Low - 12V - Chain Ø10 mm	GO	12	1000	21	12 to 16 m	85	10	12-16	890	223	110	[02.519.10]	[02.590.01]	28	18	[02.511.01]	[02.516.12]	~~€2,209.00~~ €2,166.90
G025008-112	add to cart	-	High - 12V - Chain Ø8 mm	GD	12	1000	23	12 to 16 m	85	8	12-16	890	223	110	[02.519.08]	[02.590.01]	28	18	[02.511.02]	[02.516.12]	~~€2,454.00~~ €2,408.80
G025010-112	add to cart	-	High - 12V - Chain Ø10 mm	GD	12	1000	23	12 to 16 m	85	10	12-16	890	223	110	[02.519.10]	[02.590.01]	28	18	[02.511.02]	[02.516.12]	~~€2,449.00~~ €2,403.10
G025008-024	add to cart	-	Low - 24V - Chain Ø8 mm	GO	24	1000	21	12 to 16 m	60	8	12-16	1020	223	90	[02.519.08]	[02.590.02]	30	20	[02.511.01]	[02.516.24]	~~€2,224.00~~ €2,179.70
G025010-024	add to cart	-	Low - 24V - Chain Ø10 mm	GO	24	1000	21	12 to 16 m	60	10	12-16	1020	223	90	[02.519.10]	[02.590.02]	30	20	[02.511.01]	[02.516.24]	~~€2,214.00~~ €2,174.00
G025008-124	add to cart	-	High - 24V - Chain Ø8 mm	GD	24	1000	23	12 to 16 m	60	8	12-16	1020	223	90	[02.519.08]	[02.590.02]	30	20	[02.511.02]	[02.516.24]	~~€2,464.00~~ €2,415.90
G025010-124	add to cart	-	High - 24V - Chain Ø10 mm	GD	24	1000	23	12 to 16 m	60	10	12-16	1020	223	90	[02.519.10]	[02.590.02]	30	20	[02.511.02]	[02.516.24]	~~€2,459.00~~ €2,410.20
G025001	add to cart	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	~~€249.50~~ €242.90
